GENERAL TESTING

Function, etc. Testing

• Clean facilities
• Operational testing facilities

Standard test carried out on all valves include testing of body soundness and valve tightness and an operational test for the valve and accessory assembly. Other test are agrees according to the customer's application requirements.

Laboratory Testing

HANIL laboratory facilities include resources and equipment for testing the performance of all products under actual conditions of service. High temperature/high pressure test can be performed according to any requirements in the boiler test ring. Some special testing, such as vibrational test, is subcontracted to recognized and government supported laboratories.

List of tests performed in HANIL laboratories:

• Tightness test with gas and liquid under various pressures
• Tightness test with gas using He-mass spectrometer
• Tightness test under pipe stresses
• Measurement of control properties
• Actuator testing

Non Destructive testing

Magnetic Particle Examination (MT)

Liquid penetrant examination (PT)

• Both dipping and spray can methods
• Water-soluable and chroride free solvent

Ultrasonic examination (UT)

Positive alloy material identification (PAMI)

Radiographic examination

EQUIPMENT

Film Detector	4-1/2"x17"	1 Set
Dry Film Thickness	300T/Min.	1 Set
Digital Thermometer	-40Deg. ~1100Deg.	-
Density Meter	30x2000	1 Set
Brinnel Hardness Tester	No.5	1 Set
High Frequency Generator	10KVA	3 Sets
High Frequency Grinder	7"	6 Sets
High Frequency Grinder	4"	2 Sets
Hydro. Pump	100Kg/cm2	2 Sets
Hydro. Tester for Valve	500Ton	1 Sets
Hydro. Chain Pulling Machine	5Ton	1 Sets
Multi Function Tester	-	1 Sets
